SY Electronics SY-2A-20W Amplifier

2 AUDIO INPUTS + MICROPHONE/LIN MIXER 2X20W CONTROL PANEL RS232

Audio Systems: SY-2A-20W

Description

SY-2A-20W is a digital amplifier (Class-D) with 2 line & 1 mic inputs, it supports EQ control and microphone mix. With 2 x 20W@4ohm as default output, it can also be switched to 1 x 40W@8ohm by bridge connection. The SY-2A-20W includes a 24V power supply for optimum performance and can be controlled by RS232.

Warranty: 2 years

Visit the manufacturer's website.

Features

No featured listed

Accessories

  • SY-2A-20W Amplifier
  • 24V Power Supply

Specifications

  • Product Code: SY-2A-20W
  • Manufacturer: SY Electronics Ltd
  • RS232 Ports: 3-way terminal
  • Product Dimensions: 38 mm (H): 96 mm (W): 87 mm (D)
  • Product Weight: 300 g
  • Power Consumption: 1.4 W max
