    The Casio Large Venue Projector XJ-L8300HN brings Ultra HD presentations to larger audiences through its 4K UHD technology and 5,000 lumens brightness.

    Adding to the Casio Large Venue Projector XJ-L8300HN lamp-free line up is the NEW 4K UHD model featuring a brightness of 5,000 lumens. The XJ-L8300HN is equipped with a 4K ULD chip supporting an ultra-high-definition resolution of 3840 × 2160 pixels. This offers audiences exceptionally sharp and detailed images with bright and vivid colour reproduction. The built-in lens shift function auto corrects the visual positioning of the image without reducing the resolution, ensuring the highest possible image quality is projected. The latest addition to the Casio range is ideal for halls and seminar rooms, rental & staging market, visitor attractions, command and control environments and CAD design work where the benefits of high brightness and 4K UHD resolution can really be appreciated.

    • 5,000 Lumens
    • 4K Ultra HD Resolution
    • Industry-leading warranty
    • Optical Zoom 1.5x
    • Lamp-free
    • 20,000 hour lifetime


    Casio Large Venue Projector Features

    • 5,000 Lumens
    • 4K Ultra HD Resolution
    • Industry-leading warranty
    • Optical Zoom 1.5x
    • Lamp-free
    • 20,000 hour lifetime


    Casio Large Venue Projector Specifications

    Large Venue Series XJ-L8300HN-UJ

    Technology 4K UHD DLP® chip
    Light Source Laser
    Life Expectancy 20,000 Hours
    Brightness (ANSI Lumens) 5,000
    Intelligent Brightness Control -
    Contrast Ratio 20,000 : 1
    Native Resolution 4K UHD (3840 x 2160 pixels)
    Max Signal Resolution 3840 × 2160
    Fan Noise Normal mode: 39dB (@25°C) Eco mode: 36dB (@25°C)360 degree & portrait mode: 38dB (@25°C)
    Keystone Correction (Vertical) -
    Screen Size (Diagonally) 95 - 200”
    Speaker -
    Instant Off Yes
    Time to Full Brightness 30 secs
    Colour White
    Dimensions (W x D x H)mm 471 x 565 x 206
    Weight 19.8kg
    Box Contents Wireless remote control (YT-310), Test batteries (AA size ×2), 1 x AC power cord (3.0m), 2 x Cable tie set, Rubber cap, Safety Precautions, Warranty Card, User Manual
    Throw Ratio 1.38-2.02:1

    Throwing Distance

    95" Screen 2.89m to 4.25m
    200" Screen 6.09m to 8.96m


    Standard Zoom 1.5 x optical zoom (manual)
    Focus Manual
    Offset 100%

    Power Consumption

    Eco Off Bright Mode: 545W Normal Mode: 410W
    Eco On Level 1 -
    Standby 0.5W


    Digital Input 1 x HDMI Type A, (HDMI2.0/HDCP2.2), 1 x HDMI Type A, (HDMI1.4/HDCP1.3)
    Video -
    S-Video -
    Component Video -
    RS-232C serial RS-232C (D-sub 9 pin)
    WLAN No
    LAN terminal 1 x RJ-45
    USB 1 x Type-A/DC 5V 2A
    Interactive pointing -


    Input 1 x 15-pin RGB mini D-sub
    Output 1 x 15-pin RGB mini D-sub


    Input -
    RCA R/L terminals -
    Output 1 x 3.5 mm stereo mini jack


    No accessories listed
