Epson EB-680 teaching projector specifications
Tech Specs
Product features and specifications are subject to change without prior notice.
If the projector is suspended from a ceiling or wall mount and installed in an environment with heavy oil smoke or places where oils or chemicals are volatilized, places where a lot of smoke or bubbles are used for event staging, or where aroma oils are frequently burned, it can make certain parts of our products susceptible to a material degradation which over time could break and cause the projector to drop from the ceiling.
If you are concerned about the environment in which your projector is installed, or if you have any other questions, please contact our support department and they can provide additional assistance.
Technology
Projection System 3LCD Technology
LCD Panel 0.55 inch with D9
Color Light Output 3,500 Lumen- 2,900 Lumen (economy) In accordance with ISO 21118:2013
White Light Output 3,500 Lumen - 2,900 Lumen (economy) In accordance with ISO 21118:2013
Resolution XGA, 1024 x 768, 4:3
Aspect Ratio 4:3
Contrast Ratio 14,000 : 1
Light source Lamp
Lamp 250 W, 5,000 h durability, 10,000 h durability (economy mode), 9,000 h durability (economy mode)
Keystone Correction Manual vertical: ± 3 °, Manual horizontal ± 3 °
Colour Video Processing 10 Bits
2D Vertical Refresh Rate 100 Hz - 120 Hz
Colour Reproduction Upto 1.07 billion colours
Optical
Throw Ratio 0.32 - 0.43:1
Zoom Digital, Factor: 1 - 1.35
Lens Optical
Screen Size 55 inches - 93 inches
Projection Distance Wide 0.4 m ( 56 inch screen)
Projection Distance Tele 0.6 m ( 93 inch screen)
Projection Lens Focal Length 3.7 mm
Projection Lens Focus Manual
Offset 7 : 1
Connectivity
USB Display Function 3 in 1: Image / Mouse / Sound
Interfaces USB 2.0 Type A, USB 2.0 Type B, RS-232C, Wired Network, Wireless LAN IEEE 802.11b/g/n (optional), VGA in (2x), VGA out, HDMI in (3x), Composite in, RGB in (2x), RGB out, MHL, Stereo mini jack audio out, Stereo mini jack audio in (3x), Microphone input
Epson iProjection App Ad-Hoc / Infrastructure
Advanced Features
Security Kensington lock, Control panel lock, Password lock, Padlock, Security cable hole, Wireless LAN unit lock, Wireless LAN security, Password protection
2D Colour Modes Dynamic, Cinema, Presentation, sRGB, Blackboard
Other features Auto brightness adjustment, Automatic input selection, Built-in speaker, CEC compatible, Customizable user logo, Digital zoom, Direct Power on/off, Document Camera Compatible, Dynamic lamp control, Easy OSD pre-setting, Home Screen, Long lamp life, Split-Screen-Function
Interactivity No
Video Color Modes Blackboard, Dynamic, Presentation, Sports, sRGB, Theatre, Whiteboard
Projector control via: AMX, Crestron, Control4
General
Power consumption 354 Watt, 309 Watt (economy), 0.37 Watt (standby)
Supply Voltage AC 100 V - 240 V, 50 Hz - 60 Hz
Product dimensions 367 x 400 x 149 mm (Width x Depth x Height)
Product weight 5.7 kg
Noise Level Normal: 35 dB (A) - Economy: 30 dB (A) - Eco2: 29 dB (A)
Supported Temperature Operation 5° C - 40° C, Storage -10° C - 60° C
Supported Humidity Operation 20% - 80%, Storage 10% - 90% If the projector is suspended from a ceiling or wall mount and installed in an environment with heavy oil smoke or places where oils or chemicals are volatilized, places where a lot of smoke or bubbles are used for event staging, or where aroma oils are frequently burned, it can make certain parts of our products susceptible to a material degradation which over time could break and cause the projector to drop from the ceiling.
If you are concerned about the environment in which your projector is installed, or if you have any other questions, please contact our support department and they can provide additional assistance.
Included Software iProjection
Options Air filter ELPAF38, Connection and control box, Document camera, External Speaker, Quick wireless USB key, USB extension cable, Wireless LAN unit
Compatible Operating Systems Mac OS 10.10.x, Mac OS 10.7.x, Mac OS 10.8.x, Mac OS 10.9.x, Ubuntu 14.10, Ubuntu 15.04, Ubuntu 15.10, Ubuntu 16.04 LTS, Windows 10, Windows 8, Windows 8.1
Loudspeaker 16 Watt
What's in the box CD Manual, Main unit, Power cable, Quick Start Guide, Remote control incl. batteries, Wall hanging bracket, Warranty card
Room Type / Application Meeting room / Classroom
Positioning Wall Mounted
Colour White / Grey
TCO Certified Yes
