    EPSON EB-L630U Projector

    As the market leader in 3LCD technology, Epson continues to improve its high brightness laser projectors with even smaller and more compact display solutions. The EB-L630U delivers even more effective, practical and creative display applications across a number of different industries. The EB-L630U is capable of up to 500-inch displays, without any reduction in clarity or vivid detail.

    Enhanced connectivity
    This display solution offers many different ways to connect, show multiple sources simultaneously and present wirelessly. The EB-L630U comes equipped with future-proofed connectivity options including HDMI and HDBaseT with 4K signal support, 5GHz wireless with enterprise security, upgraded Miracast, builtin media player and support for Epson’s ELPWP10 wireless presentation system.
    Easy and flexible installation
    This stylish and compact projector supports 360 degree installation without compromising the display quality and supports 16:6 ultra-widescreen, HDMI output and edge blending for multi-projector installs.


    • 6,200-lumen brightness
    • Crisp images and bright colours, even in well-lit rooms
    • WUXGA resolution
    • Sharp Full HD images for excellent clarity
    • Futureproofed connectivity options
    • 4K input support, HDMI, HDBaseT, integrated Wi-Fi and screen mirroring
    • Easy, flexible installation
    • Lightweight and compact design with wide lens shift
    • Support social distancing
    • Scalable display size of up to 500 inches


    Power consumption 345 Watt, 258 Watt (economy), 0.3 Watt (standby), On mode power consumption as defined in JBMS-84 287 Watt
    Supply Voltage AC 100 V - 240 V, 50 Hz - 60 Hz
    Product dimensions 440‎ x 339 x 136 mm (Width x Depth x Height)
    Product weight 8.4 kg

    Noise Level Normal: 38 dB (A) - Economy: 27 dB (A)
    Supported Temperature Storage -10° C - 60° C
    Supported Humidity Operation 20% - 80%, Storage 10% - 90%

    If the projector is suspended from a ceiling or wall mount and installed in an environment with heavy oil smoke or places where oils or chemicals are volatilized, places where a lot of smoke or bubbles are used for event staging, or where aroma oils are frequently burned, it can make certain parts of our products susceptible to a material degradation which over time could break and cause the projector to drop from the ceiling.

    If you are concerned about the environment in which your projector is installed, or if you have any other questions, please contact our support department and they can provide additional assistance.

    Options Connection and control box, Document camera, External Speaker, HDBaseT Transmitter, MB22 ceiling mount, Wireless LAN unit
    Loudspeaker 10 Watt
    What's in the box Cable cover, Main unit, Power cable, Remote control incl. batteries, User guide, Warranty Documents

    Room Type / Application Boardroom, Large Meeting Room / Auditorium, Meeting room / Classroom, Projection Mapping, Signage / Retail, Visitor Attraction
    Positioning Ceiling Mounted, Desktop
    Colour White
    TCO Certified For further information relating to TCO Certified please visit


    • Adapter - ELPAP11 Wireless LAN (5GHz)
    • Air Filter - ELPAF56 - L600/EB-14XX Series
    • Ceiling Mount (White) - ELPMB22
    • Ceiling Mount (Low profile) - ELPMB30
    • Ceiling Pipe (450mm) - ELPFP13
    • Ceiling Pipe (700mm) - ELPFP14
    • Safety Wire - ELPWR01
    • Ceiling Mount - ELPMB68
    • Portrait Adaptor - ELPMB69 - For ELPMB68
