    NEC Laser Projector P525UL visible yet noiseless

    NEC Laser Projector P525UL scalable visualisation has never been so silent. With an outstandingly low noise level of just 22dB*, the P525UL is quieter than the ticking of a watch.

    Thanks to the completely sealed engine, this laser projector is filter-free meaning 20,000 hours of maintenance-free operation. Comprehensive connectivity and optional WiFi provide the utmost flexibility and time saving operation. The enhanced embedded MultiPresenter functionality enables wireless presentation and screen sharing for up to 16 devices simultaneously, out of the box to your meeting room. The technology is future-proof with the capability of processing 4K inputs at 30Hz. Bringing the future of projection to your meeting room has never been easier, quieter and as low maintenance than with the NEC P525UL.

    • Type LCD
    • Brightness [AL] 5000
    • Contrast 500000:1
    • Resolution 1920 x 1200
    • Light Source Laser
    • Light Source Life [h] 20000
    • Weight [kg] 9.7
    • Order Code 60004708


    *in Eco mode / normal mode: 24 dB / High Bright mode: 27 dB


    NEC Laser Projector P525UL  Benefits

    • No filter service required – a completely sealed optical laser LCD engine allows a filter-free design. Brilliant colour brightness is maintained and servicing costs need no longer feature in your budget.
    • Low Noise Level – with 22dB*, the silent technology will not disturb your meeting.
    • Future-proof input management – thanks to 4K@30 Hz input processing.
    • Minimised Carbon Footprint – with only 320W power consumption in normal mode for lowering your TCO.
    • No lamp replacement – up to 20,000 h maintenance free operation possible due to Laser Light Source.
    • Risk Group 2 saves you installation and operation effort – because of the Risk Group 2 compliance, no prescribed safety precautions are necessary.
    • Professional and Flexible Installation – versatile projection characteristics allow for simple positioning of the projector, making installation easy and potentially saving set up costs.

    Awards and Test Reports

    2019 AV Technology

    The P525UL has won the AV Technology Europe Best of Show 2019 award at ISE

    2019 AV Awards

    The NEC P525UL, the first in our evolving line up of super silent laser projectors, is awarded 'Projection Technology of the Year' at the AV Awards!

    2019 AV Views

    The test report of the AV Views praises the extremly low noise level of the P525UL - amongst several other outstanding features. The test report is available in German only.


    Download Specifications Sheet

    NEC Laser Projector P525UL Specifications


    Projection Technology 3LCD Technology
    Native Resolution
    1920 x 1200 (WUXGA)
    Aspect Ratio 16:10
    Contrast Ratio 1 500000:1
    Brightness 1 5000 ANSI Lumen (approx. 60% in Eco Mode)
    Lamp Laser Light Source
    Light Source Life [hrs] 20000 2
    Lens F= 1.5–2.1, f= 17.2–27.6 mm
    Lens shift H:±29, V:+60,-0
    Keystone correction +/- 30° manual horizontal / +/- 30° manual vertical
    Projection Factor 1.23 – 2 : 1
    Projection Distance [m] 0.8 – 13.5
    Screen Size (diagonal) [cm] / [inch] Maximum: 762 / 300"; Minimum: 76.2 / 30"
    Zoom Manual; x1.6
    Focus Adjustment Manual
    Supported Resolutions
    3840x2160 @ 30hz digital;
    3840 x 2160 (Maximum resolution of digital input);
    1920x1200 (Maximum resolution of analog input)


    RGB (analog) Input: 1 x Mini D-sub 15 pin
    Digital Input: 1 x HDBaseT; 2 x HDMI™ supporting HDCP
    Audio Input: 1 x 3.5 mm Stereo Mini Jack for Computer analog; 2 x HDMI audio
    Output: 1 x 3.5 mm Stereo Mini Jack (variable)
    Control Input: 1 x D-Sub 9 pin (RS-232) (male)
    LAN 1 x RJ45; Optional WLAN
    USB 1 x Type B (for Service); 1x Type A (USB 2.0 high speed) with 2.0A Power Supply
    Video Signals NTSC 3.58; NTSC 4.43; PAL; PAL-M; PAL-N; PAL60; SECAM


    Remote Control Aspect Ratio; Audio Control; Auto Adjust; Eco Mode Control; Freeze-function; Help-function; ID set; Keystone Correction; Magnify-function; Page (up, down); Picture Adjust; Picture Mute; Power (On-OFF); Presentation and Mouse Control; Select (up, down, left, right); Source Select


    Power Supply 100-240 V AC; 50 - 60 Hz
    Power Consumption [W] 320 (Normal) / 238 (Eco) / 1.6 (Network Stand-by) / 0.3 (Stand-by)


    Dimensions (W x H x D) [mm] 480 x 122 x 407 (without lens and feet)
    Weight [kg] 9.7
    Fan Noise [dB (A)] 22 / 24 / 27 (ECO / Normal / High Bright)
    Colour Versions White


    Operating Temperature [°C] 5 to 40
    Operating Humidity [%] 20 to 80
    Storage Temperature [°C] -10 to 50
    Storage Humidity [%] 20 to 80


    Safety and Ergonomics CE; EAC; ErP; RoHS; TUEV Type Approved; TüV GS
    Speakers [W] 1 x 20 (mono)


    Special Characteristics Auto Power ON/OFF; Carbon Savings Meter; Constant Brightness Mode; Control ID Function; DICOM Simulation; Direct Power-Off Function; Free Tilt; HDBaseT; Help Function; HTTP Browser Control; Kensington security slot; Keypad Lock; Light Source Adjustment; Magnify; Mouse Control with USB Display; MultiPresenter Function; NaViSet Administrator 2; Optional User Logo; OSD with 30 languages; Password Security System; Plug&Play W-LAN Option; Portrait Setting; Quick Start; Source Select with Beep Function; Test Pattern; Unique Power Saving Functions; USB Viewer; Virtual Remote for direct PC control


    Ecological Materials Downloadable manuals; ECO packaging
    Ecological Standards ErP compliant; RoHs compliant


    Projectors 3 years pan-European service
    Light Source 3 years or 10000h (whatever comes first)


    Shipping Contents 2x AAA Batteries; IR Remote Control (477E); Mini D-SUB Signal Cable (1.8 m); Power Cord (1.8 m); Projector; Quick Setup Guide; Security Sticker; Users Manual; Utility software


    Optional Accessories Universal Ceiling Mounts (PJ01UCM, PJ02UCMPF); Wireless LAN module (NP05LM2; NP05LM4; NP05LM5)1 Compliance with ISO21118-2012 2 50% of initial brightness at the end of specified laser life time at 25 degree ambient temperature.

    Compliance & Declarations

    TUEV Type Approved
    TüV GS
