Description

Warranty: 3 years warranty incl. backlight

You can now enjoy all the benefits of NEC MultiSync E557Q display while keeping your price-conscious approach to spending.

The NEC MultiSync E557Q display is the perfect introduction to the world of professional digital signage. Bring NEC’s renowned performance and dependable quality into your meeting room or retail space and see just how seamlessly it will meet your digital signage needs.

The NEC E series impressively displays your retail content and is easy enough to use in daily meetings. You’ll enjoy the MediaPlayer’s native UHD content playback – which can be used automatically via the integrated playback tool. The 10W powered USB interface that lets you power external devices like the Raspberry Pi to upgrade the computing power of the display. For instant meeting start-ups, the display comes equipped with auto wake-up, which wakes up the screen once a notebook is connected. The NaViSet Administrator 2 is engineered to provide remote support, supporting E Series displays from 7th generation onwards.

Features

NEC MultiSync E557Q display features

Reduced Installation and Operating Costs

Highly energy efficient LED backlit display ensures low power consumption, longer backlight lifetime and lighter design for easy transportation, mounting and integration.

Slim Design and Integrated Speakers

The aesthetic design is pleasing to the eye and enables easy, low cost installation.

Future Ready Connectivity

Featuring multiple industry standard digital and analogue signal inputs for flexible integration into AV infrastructures.

Standalone operation

The display is designed for straightforward standalone operation due to integrated USB media player, speakers and scheduling functionality.

Effortless content playback

The integrated USB media player supports various image video file formats for effortless and standalone content playback.

Specifications


Download Specifications Sheet

NEC MultiSync E557Q display specifications

Display

Display number of colours 1.073 billion colors
LED backlighting type Direct-LED
Touchscreen No
Active display area (W x H) 1210 x 680 mm
Display type LED
Display diagonal 139.7 cm (55")
Display resolution 3840 x 2160 pixels
Display brightness 350 cd/m²
HD type 4K Ultra HD
Response time 8 ms
Contrast ratio (typical) 4000:1
Viewing angle, horizontal 178°
Viewing angle, vertical 178°
Pixel pitch 0.315 x 0.315 mm
Display diagonal (metric) 139 cm
Vertical scan range 23 - 70 Hz
Native aspect ratio 16:9
Horizontal scan range 15 - 134 kHz
Maximum refresh rate 60 Hz

Ports & interfaces

USB port Yes
HDMI version 2.0
Wi-Fi No
Ethernet LAN Yes
HDMI ports quantity 3
Ethernet LAN data rates 10,100 Mbit/s
DVI port No
VGA (D-Sub) input ports 1
Composite video in 1
Component video (YPbPr/YCbCr) in 1
Audio (L/R) in 1
Audio (L/R) out 1
Ethernet LAN (RJ-45) ports 1
RS-232 interface Yes
USB version 2.0
USB ports quantity 2

Audio

Number of built-in speakers 2
RMS rated power 20 W
Built-in speaker(s) Yes

Design

Design Digital signage flat panel
Placement supported Indoor
Orientation Horizontal
Bezel width (top) 1.29 cm
Bezel width (side) 1.29 cm
Bezel width (bottom) 1.47 cm
Product colour Black
Panel mounting interface 400 x 200 mm

Certification

EMC Class B, FCC, PSB, RCM, TÜV S, UL/C-UL, VCCI
VESA mounting Yes

Performance

Purpose Universal
Ambient light sensor Yes
Wi-Fi No

Power

Energy efficiency class A
Annual energy consumption 151 kWh
Power consumption (typical) 110 W
Power consumption (standby) 0.5 W
AC input voltage 100 - 240 V
AC input frequency 50 - 60 Hz
Energy Star certified Yes

Computer system

Computer system No
Video formats supported AVI,M-JPEG,MKV,MP4,MPEG,MPEG2-PS,MPEG2-TS,MPG
Audio formats supported AAC,AC3,LPCM,MP3,WMA

Weight & dimensions

Width 1239 mm
Depth 79 mm
Height 712 mm
Weight 15 kg

Packaging content

Handheld remote control Yes
Manual Yes
Cables included AC,HDMI
Operational conditions
Operating temperature (T-T) 0 - 40 °C
Operating relative humidity (H-H) 10 - 80%
Storage temperature (T-T) -10 - 60 °C
Storage relative humidity (H-H) 5 - 85%

Certificates

Energy Star certified Yes
Certification EMC Class B, FCC, PSB, RCM, TÜV S, UL/C-UL, VCCI

Technical details

VESA mounting Yes
LED backlighting type Direct-LED
Ambient light sensor Yes

Thin Client

Video formats supported AVI,M-JPEG,MKV,MP4,MPEG,MPEG2-PS,MPEG2-TS,MPG
Audio formats supported AAC,AC3,LPCM,MP3,WMA
Packaging data
Handheld remote control Yes
Manual Yes
Cables included AC,HDMI

Other features

Wi-Fi No
Energy efficiency class A
Bezel width (top) 1.29 cm
Bezel width (side) 1.29 cm
Bezel width (bottom) 1.47 cm
Annual energy consumption 151 kWh

Accessories

No accessories listed
